1中空玻璃自動打膠機的調整與操作

　　Adjustment and operation of automatic gluing machine for insulating glass

　　關于中空玻璃自動打膠機小編已經和大家說了很多，比如關于行業額發展、整體的現狀，還有和中空玻璃相關行業的知識等等。今天小編就和大家清清楚楚的說清楚關于中空玻璃自動打膠機的調整與操作的問題。

　　I have already talked a lot about the automatic gluing machine for insulating glass, such as the development of the industry, the overall situation, and knowledge related to the insulating glass industry. Today, the editor will explain clearly to everyone the issues related to the adjustment and operation of the automatic gluing machine for insulating glass.

　　操作流程：

　　Operation process:

　　1、放在一個平整干凈的平面上，連接電源和氣源，兩者確認接通之后就開始進行操作。

　　1. Place it on a flat and clean surface, connect the power and gas sources, and start the operation after confirming that they are connected.

　　2、打膠機中間會(huì )有一個混膠過程，在供膠機上面混膠完畢之后，需要在電子顯示屏上控制面板上進行選擇“行走設置”。在機頭停止時，打開機頭上面B膠閥門，接著在控制面板上找到Esc鍵返回主界面，然后F2狀態設置，在打開界面后按K3鍵供膠開始，當膠嘴中完全混合的膠流出按K4鍵結束供膠

　　2. There will be a mixing process in the middle of the glue machine. After the glue is mixed on the glue supply machine, it is necessary to select "walking setting" on the control panel of the electronic display screen. When the machine head is stopped, open the B glue valve on top of the machine head, then find the Esc key on the control panel to return to the main interface, and then set the F2 status. After opening the interface, press the K3 key to start glue supply. When the glue nozzle is completely mixed and flows out, press the K4 key to end glue supply

　　3、需要記住的是工作結束之后或者在較長時間不工作時，需要沖洗混膠裝置，防止供膠管的堵塞，影響未來使用效果。

　　3. It should be remembered that after work or when not working for a long time, the mixing device needs to be flushed to prevent blockage of the supply hose and affect future use.

　　4、調整環節：吸盤調整：涂膠機吸盤與旋轉臺的高度調整合適。

　　4. Adjustment process: Suction cup adjustment: Adjust the height of the suction cup and rotating table of the glue coating machine appropriately.

　　“

　　“

　　5、氣動開關、膠嘴、探針調整：將事先合好的中空玻璃放在旋轉臺上，靠近涂膠機工作面，然后中空玻璃推到定位上，調整膠嘴與玻璃的高度，使出膠嘴的出膠口中心語鋁槽中心在同一個水平線上：膠嘴與玻璃之間的頂力合適：鋁槽深度檢測探針與出膠口中心線在統一水平線上。

　　5. Pneumatic switch, nozzle, probe adjustment: Place the pre closed insulated glass on the rotating table, close to the working surface of the glue coating machine, and then push the insulated glass to the designated position. Adjust the height between the nozzle and the glass, so that the center of the glue outlet of the nozzle is on the same horizontal line as the center of the aluminum groove. The pushing force between the nozzle and the glass is appropriate. The depth detection probe of the aluminum groove is on the same horizontal line as the center line of the glue outlet.

　　6、啟動開關（機頭的最前端的光開關）與玻璃之間的檢測距離（1.5~2mm）。在控制面板上選擇“狀態設置”，打開狀態設置后選擇“吸盤開（K5鍵）”，此時機頭會(huì )往前移動，如果不往前移動則檢查并調整啟動開關的檢測距離。

　　6. The detection distance between the start switch (the optical switch at the forefront of the machine head) and the glass is 1.5~2mm. Select "Status Settings" on the control panel, open the status settings and select "Suction Cup On (K5 key)". At this time, the machine head will move forward. If it does not move forward, check and adjust the detection distance of the start switch.
